Tablet Four-Usage Tester

MULTITEST-4

Tablet Four-Usage Tester is an ideal equipment used for quality control of solid dosage forms. It is used in pharmaceutical industry, universities, research institutes, etc.

Standard Accessories:

Beaker

Nacelles units

Mercury thermometer

Bath box

Bulb syringe

Plastic hose

Brush

Vessels

Paddle units

Rotating basket units

Covers

Filter paper

Sampling cannula

Syringe filter

ORDER NOW

Tablet Four-Usage Tester is a basic equipment used for quality control of solid dosage forms. This device has four tests: dissolution, disintegration, friability, and hardness. It can be operated easily, and it has a high performance, accuracy, and sensitivity. It is widely used in pharmaceutical industry, universities, research institutes, etc.

Key features:

1) Heating, dissolution, timer, and friability functions with indicator lights.

2) Four LED displays are used to individual set velocity, time, and temperature and to view measurement of hardness.

3) Bath box is made of transparent acrylic.

4) Efficient temperature and circulation systems.

Temperature range: 20 - 45°C

Temperature stability: ± 0.3°C

Speed range: 20 - 200 rpm

Speed accuracy: ± 2 rpm

Timing range: 1 - 900 min

Timing accuracy: ± 0.5 min

External size: 580 x 380 x 480 mm

Weight: 31 kg

Power: 600 W

Power supply: AC 110V, 60Hz

• Disintegration

Nacelles: 2

Nacelle glass tubes: 6

Volume of beaker: 1000 mL

Nacelle up and down frequency: 30-32 times/minute

Nacelle up and down range: 59±2 mm

• Dissolution

Basket units: 3

Paddle units: 3

Basket radial run-out: ± 1.0 mm

Paddle radial run-out: ± 0.5 mm

Centering: ± 2.0 mm

• Friability

Drum: 1

Drum diameter: Ф 286 mm

Drum depth: 39 mm

Tablet fall height: 156 mm

Rotation speed: 25 rpm

Rotation speed accuracy: ± 1 rpm

• Hardness

Hardness range: 2 - 200 N

Probe procession range: Approx. 1 - 20 mm
